Pengaruh Arus dan Tegangan Pengelasan SMAW Baja Karbon Rendah Grade A dan Baja Karbon Rendah Grade B terhadap Sifat Mekanik

Muizzaddin Waaddulloh, Sulardjaka Sulardjaka, Gunawan Dwi Haryadi

Abstract


Penelitian ini bertujuan meneliti pengaruh arus dan tegangan terhadap kekuatan tarik, kekuatan impak, kekerasan dan struktur mikro pada hasil pengelasan baja A242 dan baja A588. Pengelasan SMAW menggunakan elektrode E7016 DC+ polaritas terbalik dan elektrode AWS A5.1 tipe RD 260 diameter 3.2 mm dengan variasi arus pengelasan: 60A, 120A, dan 180A, serta variasi tegangan pengelasan: 20,30 dan 40 dengan kecepatan 50 [mm/min]. Jenis kampuh sambungan yang digunakan yaitu single “V” Groove sudut 60º. Pengujian tarik dilakukan berdasarkan standar ASTM E 8M-04, standar pengujian impak berdasarkan ASTM E23, standar pengujian struktur mikro berdasarkan ASTM E407, dan untuk standar pengujian kekerasan mikro vikers berdasarkan ASTM E92. Setelah melakukan pengujian dan pembahasan diketahui bahwa menggunakan variabel arus dan tegangan yang besar sangat memengaruhi dari hasil nilai kekuatan Tarik dan pengujian impak. Hal tersebut disebabkan oleh faktor adanya perbedaan dalam metode pengelasan dan panas yang diterima (heat input), sehingga memiliki struktur mikro yang berbeda pula. Hasil pengujian struktur mikro juga menghasilkan struktur ferit, pearlit dan juga memperlebar butiran las pada daerah weld metal.


Keywords


impact strength; tensile strength; micro structure; micro hardness of vikers

Full Text:

PDF

References


S. I. Talabi, O. B. Owolabi, J. A. Adebisi, and T. Yahaya, “Effect of welding variables on mechanical properties of low carbon steel welded joint,” Adv. Prod. Eng. Manag., 2014, doi: 10.14743/apem2014.4.186.

D. Pathak, R. P. Singh, S. Gaur, and V. Balu, “Experimental investigation of effects of welding current and electrode angle on tensile strength of shielded metal arc welded low carbon steel plates,” 2019, doi: 10.1016/j.matpr.2020.01.146.

T. Shiozaki, N. Yamaguchi, Y. Tamai, J. Hiramoto, and K. Ogawa, “Effect of weld toe geometry on fatigue life of lap fillet welded ultra-high strength steel joints,” Int. J. Fatigue, 2018, doi: 10.1016/j.ijfatigue.2018.06.050.

N. Yurioka, “The 70th Anniversary of Japan Welding Society-Developments in the science and Engineering of Welding and Joining toward 21th Century. Trends of Welding and Joining Engineering in Industries. Trends of welding technologies in material industries.,” J. Japan Weld. Soc., 1996, doi: 10.2207/qjjws1943.65.67.

Y. Dong, A. P. Teixeira, and C. Guedes Soares, “Fatigue reliability analysis of butt welded joints with misalignments based on hotspot stress approach,” Mar. Struct., 2019, doi: 10.1016/j.marstruc.2019.01.006.

Japan Welding Engineering Society., 2006, “ Advanced Welding and Joining Technologies”. Tokyo: Japan Welding Society.

Gea Jorge Carlos FerreiraJor,Joe lLemos Dias Mont eiroa,Antonio Joséde Ca Rvalho Gomes a,Ivanide Souza Bottb,Luís FelipeGuimarães deSouzaa, MatheusCa mpolina Mendesa, Leon ardo Sales Araújo.,2018,” Influence of welding procedureand PWHT on HSLAsteel weld metals”, sci://www.sciendirect./ S2238785417309249. Brazil:hal.1-11.

Hsuan-Han Lai and Weite Wu., 2019, “Practical examination of the welding residual stress in view of low carbon steel ”.Sci.S2214914718303453. Taiwan:hal.1-10

Dony Perdana dan Ahmad Bazy Syarif., 2017, ”Analisa Pengaruh Jenis Pengelasan SMAW dan FCAW Terhadap Sifat Mekanik Baja ASTM A36 pada kontruksi landside upper leg “. Indonesia:hal.1-4.

Saxenna Ambuj, A.Kumarwaraswarnya, G.Madhusudhan., 2018, “Influence of welding consumable on tensile and impact properties of multipass MAW.www.sciendirect.co.S214914717302167. India:hal.11

Y.Zhao, dkk., 2019, “Effects of microstructure on crack resistance and low temperature toughness ultra-low carbon high strength steel China:hal.203-215.

Leandro fr jesus dan veronica scarpini,.2018,” mechanical and micro mechanical properties of SMAW welding thermally”.Brazil:hal.14

Cheng Chen dan Sing ping chiew,.2018,” welding effect on the tensile strength of blunt joints”.China:223-226.

S. M. Manladan dan Zhang Z. Luo,” Microstructure and mechanical properties of resistance spot welded in welding-brazing mode and resistance element welded magnesium alloy/austenitic stainless steel joints”.China:124-128.

Minseok Kang dan Jeongyeon Seo,.2018,” Ship block assembly sequence planning considering productivity and welding deformation”.korea:446.




DOI: https://doi.org/10.18196/jmpm.v4i2.11450
